HLK PM01 220v to 5v AC-DC Isolated Switching Power Supply

Description Product features :  Meet  UL  and CE requirements ,Ultra-thin , ultra-smallFull voltage input ( 90~264Vac )Low ripple , low noiseOutput overload short circuit protection functionHigh efficiency and high power densityProduct design meets EMC and safety testing requirementsLow power consumption, environmental protection, no-load loss <0.1W 1.  Product features: – Meet UL, CE requirements,– Ultra-thin, ultra-small– All voltage input (AC: 90 ~ 264V)– Low ripple and low noise– Output overload and short circuit protection– High efficiency, high power density– The product is designed to meet the requirements of EMC and Safety Test– Low power consumption, environmental protection, no-load loss <0.1W– 100% load aging and testing– 1 year warranty perio 2. Environment Condition Item Name Technical Criteria   Unit Operation Temperature -20— 60 Centigrade Store Temperature -40— 80 Centigrade Relative humidity 5—95 % Cooling way Cooling by radiation   Atmospheric pressure 80—106 Kpa Sea level elevation ≤2000 m Vibration Vibration coefficient 10~500Hz,2G10min./1cycle, 60min.each along X,Y,Z axes     3.Electrical Characteristic 1. Input characteristics (test at room temperature 20 Centigrade ). Item Name Technical Criteria Unit Rated input voltage 100-240 VAc Input voltage range 90-264 VAc Maximum input current ≤0.2 A Input current surge                   ≤10 A maximum input voltage ≤270 VAc Enter slow start ≤50 mS Input Low Voltage Efficiency Vin=110VAc,Output full-load≥69 % Input High Voltage Efficiency Vin=220VAc,output full-load≥70 % Long-term reliability MTBF≥100,000 h Load rated output voltage 5±0.1 VDc Full rated output voltage 5±0.2 VDc Short-term maximum output current ≥1000 mA The maximum output current for a long time ≥600 mA Voltage Regulation ±0.2   % Load Regulation                       ±0.5 % Output ripple and noise (mVp-p) ≤50 Rated input voltage, full load. Using 20MHz of bandwidth, The load side 10uF and 0.1uF capacitor to be tested. mV Switch overshoot amplitude (Rated input voltage and output load plus 10%)≤5 %VO Output over-current protection 150-200% of the output maximum load A Output short circuit protection Direct short circuit at the normal output, automatically resume normal operation after a short circuit removal
