Deepcool PF600X 600W 80 Bronze Design Output Spec Gallery Downloads MULTIPLE BRONZE EFFICIENCY CERTIFICATIONS The *bronze efficiency obtained from 80 PLUS, Cybenetics, and PPLP, ensuring 88% efficiency under typical loads (50%), significantly reduced energy loss and heat generation while extending the service life of the PSU. *Due to the different testing standards between the institutions, all packaging and labels will use the Bronze badge to ensure uniformity and compliance. TAIWANESE JAPANESE PREMIUM CAPACITORS By using the Taiwanese premium solid and electrolytic capacitors, the PF-X series can ensure a hold-up time ≥ 16ms under 75% load, which provides reliable protection for abnormal power outages. The 5V Stand-By rail uses an electrolytic capacitor from two major Japanese brands, which have a four-fold life span compared with normal, ensuring stable standby throughout the day. RELIABLE TOPOLOGY To meet the Intel ATX 2.52 standard, using Active PFC Double Forward DC to DC, combined with a dual-stage EMI circuit. It significantly reduces ripple noise and voltage deviation, providing better electrical performance and compatibility. WIDE VOLTAGE ADAPTATION Supporting 180V-264V wide voltage operation and extreme full-load working conditions under room temperature at a 160V low-voltage grid were supported to avoid voltage instability shutdown. (Due to safety requirements, the voltage parameters of the nameplate need to leave 10% redundancy, the above is the actual support working voltage) Strict Safety Standard Strictly following global safety standards, beyond competitors, including the 40℃ and 5000m safety levels, meets the requirements for high-temperature and high-altitude areas. 40K HRS MTBF LONG-LIFE FAN A high-quality long-life bearing fan extends operational life by 30% compared to a normal fan and can continuously function for 7×24 hrs in a 40℃ environment. Meanwhile, the aerodynamic design based on PCB layout and flow resistance offers superior stability and quiet operation. High-Grade Configurations Equipped with GAMER STORM’s custom-molded sleeved cables significantly enhances the installation and wiring experience. Peace of Mind The PF-X is equipped with eight protection IC providing comprehensive safeguards, including OPP, OVP, SCP, OTP, OCP, UVP, SIP, and NLO. Over Power Protection Over Voltage Protection Short Circuit Protection Over Temp Protection Over Current Protection Under Voltage Protection Surge & Inrush Protection No Load Operation EXCEPTIONAL WARRANTY Standing behind the high standards Gamer Storm has set for our products, we provide a 3-year limited warranty to ensure worry-free service and support for our customers. Main Power Connector 24 (20 4)Pin x1 x1 CPU (4 4)Pin x2 x1 PCI-E (6 2)Pin x1 x2 AC INPUT VOLTAGE CURRENT FREQUENCY 200-240Vac 5A 50-60Hz DC OUTPUT 3.3V 5V 12V -12V 5VSB CURRENT(Max) 16A 16A 50A 0.3A 3A OUTPUT(Max) 100W 600W 3.6W 15W TOTAL OUTPUT 600W Model PF600X Model No PF600X-HD Total Output 600W Type ATX12V V2.52 Product Dimensions 150×140×86mm (W x L x H) Efficiency certification 80PLUS 230 EU Bronze/CYBENETICS Bronze /CYBENETICS A 230V/PPLP 230V Bronze Fan Size 120mm Fan Bearing Longlife HYB Topology Active PFC DC to DC Capacitors Taiwanese Japanese Electrolytic Capacitors Power Good Signal 100-150ms Hold Up Time ≥16ms(75% Load) Efficiency ≥88% Under Typical Load(50% Loading) Protection OPP/OVP/OCP/SCP/OTP/UVP/SIP/NLO Operation Temperature 0-40°C Regulatory CE/TUV-RH/CCC/RCM/KC Erp Regulation ErP 2014 Environment Protection WEEE/中国 RoHS/Triman MTBF 40,000 Hours
